Micro Cut

Classifiers Air Classifier Micro Cut

YACA-400HST

The Uras Micro Cut offers high accuracy classification across a large range of particle sizes, with an easily adjustable cut point.

"The Micro Cut" air classifier precisely and efficiently separates large and small particles. The separation point can be adjusted easily. The horizontal-type Micro Cut classifies small particles with high accuracy, while the vertical-type Micro Cut can classify large volumes and does not require the use of a bag filter. Optionally, anti-wear parts are available for handling abbrasive materials.

Details about this product

Advantages

<Horizontal-type>

Easy to adjust separation point.
Separation point can be set as low as 2µm.
Highly accurate classification.

<Vertical-type>

Easy to adjust separation point.
Highly accurate classification.
Able to classify large volumes.
Collects classification output internally, eliminating the need for bag filters and reducing required space.

Primary Applications

Removing coarse particles from talc, separation of flour particles, removal of foreign matter from soot, separation of brown iron oxide, separation of calcium carbonate

Materials that can be handled

Activated Carbon, Activated Charcoal Made from Palm Trees, Activated Clay, Alumina, Aluminum, Aluminium Hydroxide, Anthracite, Antimony, Bentonite, Calcined Kaolin, Calcium Carbonate, Calcium Silicate, Cement, Ceramics, Chamotte, Clay, Coal, Cokes, Diatomaceous Earth, Dolomite, Feldspar, Ferrite, Ferroalloy, Fine Plastic Powder, Fish Powder, Flour, Fluorine Resin, Fly Ash, Foaming Agent, Frit, Glass Cullet, Glass Powder, Gold Powder, Graphite Powder, Gypsum, Heat Insullating Material, Heavy Calcium Carbonate, Hydrated Lime, Inorganic Refractory Powder, Iron Ore, Iron Oxide, Iron Powder, Limestone, Magnesia, Magnesium Oxide, Manganese Oxide, Metal Powder, Metal Silicon, Mica, Mixed Feed, Mixed Fish Feed, Molybdenum, Olivine Sand, Pagodite, Phenol Resin, Polyethylene, Polytetrafluoroethylene, Potato Starch, Powder Coating, Pottery Stone, Quicklime, Rare Earth, Refractory Materials, Resin, Rice Powder, Ring-Shaped Graphite, Rubber Filling Material, Sericite, Silica, Silica Sand, Silicastone, Silicic Acid, Silicone Carbide, Sludge Incineration Ash, Soda Ash, Soft Ferrite, Sugar, Talc, Tire Scrap, Toner, Tooth Powder, Volcanic Ash, Wood Powder, Zeolite, Zinc, Zinc Carbonate, Zinc Oxide, Zircon Sand

Primary Users

Automotive, Ceramics, Chemical, Food, Mining, Precision

Standard Specifications

Horizontal Type

Model	Particle Size (µm)	Power (kw)	Max Handling Capacity (kg/h)
YACA-132H	2-15	2.2	20-50
YACA-400H	6-50	5.5-30	400-2500
YACA-400HS	3.5-50	7.5-22	200-1500
YACA-400HU	5-30	22	150-300

Vertical Type

Model	Particle Size (µm)	Power (kw)	Max Handling Capacity (t/h)
YACA-400V	8-100	2.2-7.5	0.3-2
YACA-600V	10-100	11-30	1-5
YACA-1000V	15-100	22-45	2-12
YACA-1350V	20-100	55-110	4-20
